Description
You can order GROOTY frame only, if you want to assemble it yourself.
Technical Specifications
|
Headset interface |
FSA ACR or DEDA DCR internal cable routing headset |
|
Bottom bracket interface |
PF30 (68mm width) |
|
Rear axle interface |
M12x1.5mm, 12×142/ 170mm |
|
Seatpost interface |
31.6mm internal diameter |
|
Tire clearance |
compatible with 28mm tires |
|
Transmission |
Electric shifting (Di2, ETAP AXS), or cable shifting, 1x1X or 2x1X (Shimano only for front derailleur with cable) |
|
Weight |
Around 2.0kg |
GROOTY frame size chart
| Size | S | M | L | XL |
| Rider mean height (cm) | 167.5 | 174.5 | 181.5 | 189.5 |
| Rider minimum height (cm) | 164.0 | 171.0 | 178.0 | 185.0 |
| Rider maximum height (cm) | 171.0 | 178.0 | 185.0 | 194.0 |
